엔코더

엔코더(Encoder)는 회전 위치와 속도, 각도 등의 움직임 정보를 전기 신호로 변환하는 위치 검출 센서입니다. 자동화 설비와 산업용 장비의 정밀 제어에 사용되며, 모터 제어·로봇·반도체 장비 등에 적용됩니다. Incremental·Absolute 방식 등 다양한 구조로 구성되며, 고정밀 위치 제어와 속도 피드백이 가능합니다. 코비스는 AMCI를 비롯한 다양한 엔코더 제품의 공급 및 기술 대응이 가능합니다.

빠른 검색을 원하시면 사양을 선택해 주세요.

1/1 page

    select * from product where pd_status='1' and c_2category='6' order by pd_favor asc limit 0, 12
  • DC25 Absolute Single-turn Analog Rotary Shaft Encoder
    • Precision12 bit analog voltage or current
    • Setting time20 mSec. max
    • Voltage 0 to 5 Vdc, 0 to 10 Vdc, ±10 Vdc
    • Load capacity(V)2K ohm min
    • Current 4-20 mA, 0-20 mA

  • DC25 Absolute Digital Single-Turn Rotary Shaft Encoder
    • Code FormatGray and Binary: 4096 counts per turn (max.) BCD 3600 counts per turn (max.)
    • Resolution12 bits
    • Drive capability15 mA max. Sink or Source
    • Requirements(P)4.75 to 26.4 Vdc | 1.5w max
    • OutputOpen Collector Sink (High or Low True)/5 to 24 Vdc out/Available with or without a 10 KΩ pull-up resistor/Open Collector Source (High or Low True)/5 to 24 Vdc out

  • DC25 Incremental Digital Single-turn Rotary Shaft Encoder
    • Code Format2 square waves in quadrature with standard gated index
    • Cycles per turn2 to 4096 factory set. optional - dip switch field-programmable
    • Frequencydata - 210 kHz (min.) | index - 125 kHz (min.)
    • OutputCurrent source, 5 to 24 Vdc Current sink, 5 to 24 Vdc Current sink with 2.2 kohm pull-up resistor Current Source with 2.2kohms pull-down resistor Differential line driver, 5 Vdc
    • Resolution“N” type, 10 bits (1024) / “T” type, 11 bits (2048) / “F” type, 12 bits (4096)

  • NR25 Networked Absolute Rotary Shaft Encoder
    • Output CodeEtherNet/IP, Modbus-TCP, Profibus-DP, or DeviceNet
    • ResolutionSingle Turn = 65536 counts max Multi Turn = (2 versions) 65536 counts / turn & 4096 turns maximum 65536 counts / turn & 16384 turns maximum
    • Direction Programmable over the network default = CW increasing looking at the shaft
    • Parameters- Direction of Increasing Counts - Counts Per Turn - Velocity Units - Preset Function - Total Measurement Range (defines the number of counts where the position rolls over to zero)
    • Time StampOptional input data that replaces the Velocity. Time stamp is an unsigned double integer value with an interval of 400 nanoseconds; rolls over every 1717.9869184 seconds

  • DC25 Absolute SSI Rotary Shaft Encoder
    • Output CodeBinary or gray code
    • Frequency1MHz (Max)
    • ResolutionSingle Turn = 4096 counts max Multi Turn = 4096 counts/turn & 4096 turns max.
    • Direction Default = CW increasing looking at the shaft CCW increasing when power is applied to pin 12, the Direction Input pin, at power up
    • Requirements(P)4.5Vdc to 26.4Vdc | 24Vdc optimal |1.92W

  • DC60 Absolute Multi-turn Analog Rotary Shaft Encoder
    • Voltage10 to 30 Vdc maximum
    • Resolution16 bit (1 part in 65,536)
    • Update Time1.6 milliseconds
    • Output Types0 to 10Vdc, 0 to 20mA, or 4 to 20mA
    • Output Time50 microseconds when switching between minimum and maximum outputs

  • NR60 Networked Absolute Rotary Shaft Encoder
    • Output CodeEtherNet/IP, Modbus-TCP, & Profinet
    • ResolutionSingle Turn = 65536 counts max Multi Turn = (2 versions) 65536 counts / turn & 4096 turns maximum 65536 counts / turn & 16384 turns maximum
    • Direction Programmable over the network default = CW increasing looking at the shaft
    • Parameters- Direction of Increasing Counts - Counts Per Turn - Velocity Units - Preset Function - Total Measurement Range (defines the number of counts where the position rolls over to zero)
    • Requirements(P)12 to 54Vdc / 2.5 W maximum / 100mA @ 24Vdc

  • ME15 Absolute SSI Rotary Shaft Encoder
    • Resolution10 bits, 1024 counts
    • Accuracy+ 0.5°
    • DirectionCW or CCW, specified when ordering
    • Measuring360 degrees continuous
    • ProtectionOver and Reverse voltage protection, short circuit protected

  • DC425 Absolute Multi-turn Analog Rotary Shaft Encoder
    • Input voltage18 to 30 Vdc 24 Vdc optimal
    • Input power3.75 W max.
    • Scale Output #1, 2, 4, 5, 10, 20, 25, 50, or 100
    • Current output4 to 20 mA 12 bit resolution per turn 16 bit resolution max.
    • Current load650 ohm @ 18Vdc input 950 ohm @ 24Vdc input 1250 ohm @ 30Vdc input

  • ME15 Absolute Analog Rotary Shaft Encoder
    • Resolution10 bits
    • Accuracy+ 0.5°
    • Direction CW or CCW, specified when ordering
    • Measuring360 degrees continuous
    • ProtectionOver and Reverse voltage protection, short circuit protected
