  H25 Single-turn Stainless Steel Resolver Transducer

  • Input Voltage7.0 V rms
  • Frequency5,000 Hz
  • Phase Shift10° max.
  • Stator Output(V)6.65 V rms
  • Accuracy max. error ±10 minutes

  상세보기

  비교담기

•

  HT-20C Single-turn Stainless Steel Resolver Transducer

  • Input Voltage7.0 V rms
  • Frequency5,000 Hz
  • Phase Shift9° max.
  • Stator Output(V)6.65 V rms
  • Accuracy max. error ±7 minutes

  상세보기

  비교담기

•

  NR25 Single&Multi-turn Networked SUS Resolver Transducer

  • Output CodeEtherNet/IP, Modbus-TCP, Profibus-DP, or DeviceNet
  • ResolutionSingle Turn = 65536 counts maxMulti Turn = (2 versions)65536 counts / turn & 4096 turns maximum65536 counts / turn & 16384 turns maximum
  • DirectionProgrammable over the networkdefault = CW increasing looking at the shaft
  • ParametersDirection of Increasing Counts / Counts Per Turn / Velocity Units / Preset Function / Total Measurement Range(defines the number of counts where the position rolls over to zero)
  • Time StampTime stamp is an unsigned double integer value with an interval of 400 nanoseconds; rolls over every 1717.9869184 seconds.

  상세보기

  비교담기
